Switching Module

products.productrange :
Products
SKU :
JQA-GRN-JNETSWM20AC008
products.short.description :
Technical Specifications:
- Cover Material: Iron
- Operating temperature :-15°C ~ +60°C
- Humidity: ≤50% RH
- Power consumption :<3W
- Environment: IP20
- Cascade signal: Optocoupler
- Master controller signal: Ethernet protocol
- Network interface: RJ45 Ethernet interface
- Output signal: TTL & RS-485 × 8 channels
- Control capacity: Up to 154 Sub-controllers or 4,00,000 channels
- Transmission distance: Use UTP (unshielded twisted pair) cable, distance between the controllers can be
- Weight: 2050 gm
- Dimension: 285mm (L) × 156mm (W) × 45mm (H)
- Pixel driven: Single chip: 960 pixels × 8 channels; Single-wire: 1024 pixels × 8 channels; Standard DMX512: 168 pixels × 8 channels; Extensible DMX: 336 pixels × 8 channels; Break-point resume: 960 pixels × 8 channels
